MinIO Cluster Deployment

• Each MinIO node needs to install Docker in advance.

Initialize Docker Swarm Environment

1. Execute the swarm initialization command on the first node, MinIO Node01.

   docker swarm init

   # The initialization command will output a join command that needs to be run on the other three nodes.
   # When there are multiple IP addresses on the server, you can specify the IP and port for other nodes to connect to the current manager node using the --advertise-addr parameter.
   # docker swarm init --advertise-addr 192.168.1.11

2. Run the join command on MinIO Node02, Node03, and Node04 to join the swarm cluster.

   docker swarm join --token xxxxxxxx

   # If the token is forgotten, you can view it on MinIO Node01 with the following command:
   # docker swarm join-token worker

3. View the nodes and record each node ID.

   docker node ls

Deploy MinIO Cluster

All the following steps need to be performed on all four servers

1. Download the image

   Server with Internet Access

   docker pull registry.cn-hangzhou.aliyuncs.com/mdpublic/mingdaoyun-minio:RELEASE.2025-04-22T22-12-26Z

   Server without Internet Access

   # Offline image package download link, please download and upload to the deployment server
   https://pdpublic.mingdao.com/private-deployment/offline/mingdaoyun-minio-linux-amd64-RELEASE.2025-04-22T22-12-26Z.tar.gz

   # Load the offline image on the server using the docker load -i command
   docker load -i mingdaoyun-minio-linux-amd64-RELEASE.2025-04-22T22-12-26Z.tar.gz

2. Create a data storage directory

   mkdir -p /data/minio/volume

The following steps need to be performed only on the first node, MinIO Node01

3. Create a configuration file storage directory

   mkdir -p /usr/local/minio

4. Create the MinIO configuration file

   cat > /usr/local/minio/minio.yaml <<'EOF'
   version: '3'
   services:
     minio1:
       hostname: minio1
       image: registry.cn-hangzhou.aliyuncs.com/mdpublic/mingdaoyun-minio:RELEASE.2025-04-22T22-12-26Z
       environment:
         MINIO_ROOT_USER: "mingdao"
         MINIO_ROOT_PASSWORD: "123456789"
       volumes:
         - /usr/share/zoneinfo/Etc/GMT-8:/etc/localtime
         - /data/minio/volume:/data/storage
       ports:
         - "9011:9000"
         # - "19111:9001" # Access port for MinIO console, uncomment if needed
       command: minio server http://minio{1...4}/data/storage/data --console-address ":9001"
       deploy:
         placement:
           constraints:
             - node.id == xxxxxxxxxxxxxxxx # Docker node.id value of MinIO Node01

     minio2:
       hostname: minio2
       image: registry.cn-hangzhou.aliyuncs.com/mdpublic/mingdaoyun-minio:RELEASE.2025-04-22T22-12-26Z
       environment:
         MINIO_ROOT_USER: "mingdao"
         MINIO_ROOT_PASSWORD: "123456789"
       volumes:
         - /usr/share/zoneinfo/Etc/GMT-8:/etc/localtime
         - /data/minio/volume:/data/storage
       ports:
         - "9012:9000"
       command: minio server http://minio{1...4}/data/storage/data --console-address ":9001"
       deploy:
         placement:
           constraints:
             - node.id == xxxxxxxxxxxxxxxx # Docker node.id value of MinIO Node02

     minio3:
       hostname: minio3
       image: registry.cn-hangzhou.aliyuncs.com/mdpublic/mingdaoyun-minio:RELEASE.2025-04-22T22-12-26Z
       environment:
         MINIO_ROOT_USER: "mingdao"
         MINIO_ROOT_PASSWORD: "123456789"
       volumes:
         - /usr/share/zoneinfo/Etc/GMT-8:/etc/localtime
         - /data/minio/volume:/data/storage
       ports:
         - "9013:9000"
       command: minio server http://minio{1...4}/data/storage/data --console-address ":9001"
       deploy:
         placement:
           constraints:
             - node.id == xxxxxxxxxxxxxxxx # Docker node.id value of MinIO Node03

     minio4:
       hostname: minio4
       image: registry.cn-hangzhou.aliyuncs.com/mdpublic/mingdaoyun-minio:RELEASE.2025-04-22T22-12-26Z
       environment:
         MINIO_ROOT_USER: "mingdao"
         MINIO_ROOT_PASSWORD: "123456789"
       volumes:
         - /usr/share/zoneinfo/Etc/GMT-8:/etc/localtime
         - /data/minio/volume:/data/storage
       ports:
         - "9014:9000"
       command: minio server http://minio{1...4}/data/storage/data --console-address ":9001"
       deploy:
         placement:
           constraints:
             - node.id == xxxxxxxxxxxxxxxx # Docker node.id value of MinIO Node04
   EOF

   • The access key for the object storage is specified by the MINIO_ROOT_USER environment variable. This is a core credential, and a strong password should be used during deployment.
   • The secret key for the object storage is specified by the MINIO_ROOT_PASSWORD environment variable. This is a critical security key, and a strong password should be used during deployment.

5. Configure start and stop scripts

   cat > /usr/local/minio/start.sh <<'EOF'
   docker stack deploy -c /usr/local/minio/minio.yaml minio --detach=false
   EOF

   cat > /usr/local/minio/stop.sh <<'EOF'
   docker stack rm minio
   EOF

   chmod +x /usr/local/minio/start.sh
   chmod +x /usr/local/minio/stop.sh

6. Start the MinIO service

   bash /usr/local/minio/start.sh

7. Check the status of each MinIO node

   docker stack ps minio
